Trendnet 24-Port 10/100Mbps Web Smart PoE Switch with 4 Gigabit Ports and 2 SFP Slots

$475.68 $597.02

SKU: TPE_224WS
MODEL: 24-Port 10/100Mbps Web Smart PoE Switch with 4 Gigabit Ports and 2 SFP Slots
Product Description The 24-Port 10/100Mbps Web Smart PoE Switch with 4 Gigabit Ports and 2 Shared Mini-GBIC Slots (model TPE-224WS) delivers a 12.8Gbps switching capacity with Power over Ethernet (PoE) technology and managed layer 2 features at a reduced cost. Support for SNMP v1, 802.1x, STP, 802.1Q VLAN, QoS, IGMP...
Quantity
Add to Wishlist

Product Description

The 24-Port 10/100Mbps Web Smart PoE Switch with 4 Gigabit Ports and 2 Shared Mini-GBIC Slots (model TPE-224WS) delivers a 12.8Gbps switching capacity with Power over Ethernet (PoE) technology and managed layer 2 features at a reduced cost. Support for SNMP v1, 802.1x, STP, 802.1Q VLAN, QoS, IGMP snooping, Broadcast Storm Control and port Trunking provide a cost effective, scalable and secure backbone PoE switch solution for SMB networks.

Product Details

Power over Ethernet (PoE) technology reduces equipment and installation costs by delivering data and power over existing Ethernet cables. SNMP support enables the switch to provide valuable status and event information, saving system administrators time and resources. Access the Web-browser management interface and segment up to 256 Virtual Local Area Networks, manage network priority with 802.1p support and dedicate bandwidth with port-based Trunking.




24 x 10/100Mbps Auto-MDIX Fast Ethernet PoE RJ-45 ports

4 x 10/100/1000Mbps Auto-MDIX Gigabit ports

2 x 1000Base-SX/LX Mini-GBIC slots (shared with Gigabit ports)
12.8Gbps switching capacity

IEEE 802.3af Power over Ethernet (PoE) compliant

PoE power of up to 15.4 watts for each PoE port

Maximum PoE power of up to 170 watts for all PoE ports

IEEE 802.3x Full Duplex Flow Control and Back Pressure

IEEE 802.3ad Port Trunk

IEEE 802.1D Spanning Tree Protocol IEEE 802.1p QoS

IEEE 802.1X Authentication and SNMP v1 support

Supports port based IEEE 802.1Q VLAN Tag and Asymmetric VLAN

Supports Auto-recognition of PoE Powered Device (PD) signature

Full Wire-Speed Non-Blocking reception and transmission

Store and Forward switching method

Integrated address look-up engine with an 8K absolute MAC address table

Supports 128KBytes RAM for data buffering

Easy configuration via Web browser

Front panel diagnostic LEDs

Standard 1U (19”) rackmount size (rackmount kit included)



  • Reduces equipment cost by delivering data and power over existing network cables
  • 24 x PoE 10/100Mbps ports, 4 x Gigabit Auto-MDIX ports and 2 x shared Mini-GBIC slots
  • 12.8Gbps switching capacity with SNMP v1, 802.1X and STP support
  • Features 802.1Q VLAN, Asymmetric VLAN, QoS, IGMP, Trunking and Mirroring

Product Specifications


Product information
Size:24-Port PoE+ | Color:Black

Technical Details

Brand Name  TRENDnet

Item model number  TPE-224WS

Item Weight  7.12 pounds

Product Dimensions  4.7 x 2.3 x 0.6 inches

Item Dimensions  L x W x H 4.7 x 2.3 x 0.6 inches

Color  Black

3 years warranty
