APC Smart-UPS 2200VA LCD 230V

$1,488.97 $1,621.15

SKU: SMT2200I/1214532/RBC55
MODEL: Smart-UPS 2200VA LCD 230V
Product Description: Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices. Includes : CD with software , Documentation CD , Smart UPS signalling RS-232 cable , USB cable Cold-start capable Provides temporary battery power when...
Quantity
Add to Wishlist

Product Description:

Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.

Includes : CD with software , Documentation CD , Smart UPS signalling RS-232 cable , USB cable

  • Cold-start capable
    Provides temporary battery power when the utility power is out.
  • Energy meter
    Provides actual kilowatt hours of usage for energy conscious users.
  • Green mode
    Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
  • High online efficiency
    Reduces utlility costs, generates less heat.
  • Intuitive LCD interface
    Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.
  • Predictive replace battery date
    Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
  • Pure sine wave output on battery
    Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
  • Sequenced network shutdown and reboot
    Customize network shutdown and reboot sequence of connected servers and UPSs.
  • Single switched outlet group
    Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.
  • SmartSlot
    Customize UPS capabilities with management cards.
  • StruxureWare Data Center Expert compatible
    Enables centralized management via StruxureWare Data Center Expert.
  • Temperature-compensated battery charging
    Prolongs battery life by regulating the charge voltage according to battery temperature.

Product Details:

Smart-UPSFeatures & Benefits

Adaptability
  • Adjustable voltage sensitivity
    Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
  • Adjustable voltage-transfer points
    Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
Availability
  • Automatic restart of loads after UPS shutdown
    Automatically starts up the connected equipment upon the return of utility power.
  • Temperature-compensated battery charging
    Prolongs battery life by regulating the charge voltage according to battery temperature.
  • Disconnected battery notification
    Warns when a battery is not available to provide backup power.
  • Automatic self-test
    Periodic battery self-test ensures early detection of a battery that needs to be replaced.
  • Boost and Trim Automatic Voltage Regulation (AVR)
    Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
  • Power conditioning
    Protects connected loads from surges, spikes, lightning, and other power disturbances.
  • Intelligent battery management
    Maximizes battery performance, life, and reliability through intelligent, precision charging.
Safety
  • Safety-agency approved
    Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Manageability
  • Disconnected battery notification
    Warns when a battery is not available to provide backup power.
  • USB connectivity
    Provides management of the UPS via a USB port (not available on all models).
  • Serial connectivity
    Provides management of the UPS via a serial port.
  • LED status indicators
    Quickly understand unit and power status with visual indicators.
  • Audible alarms
    Actively let you know if the unit is on battery, if the battery is low or if there is an overload condition.
  • Network manageable
    Provides remote power management of the UPS over the network.
Serviceability
  • Hot-swappable batteries
    Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
  • User-replaceable batteries
    Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
  • Battery failure notification
    Provides early-warning fault analysis on batteries enabling timely preventive maintenance
  • Resettable circuit breakers
    Enables a quick recovery from overload events.
  • Predictive failure notification
    Provides early-warning fault analysis ensuring proactive component replacement.
  • Marketing Features

    Save time with easy and convenient remote accessibility

    Network manageable via serial, USB or optional ethernet. Includes Powerchute® Business Edition Software for convenient monitoring and control, safe operating system shutdown and innovative energy management capabilities

    .Low operating and maintenance costs with high efficiency, proven reliability and intelligent battery management

    Patented green operating mode achieves efficiencies over 97%. Smart-ups was the first network UPS to be Energy Star certified. Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Dynamic battery replacement date indicator and automatic self tests insure battery reliability and warn in advance of needing replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down. Designed and manufactured by APC for over 23 years, Smart-UPS is the world’s most trusted network UPS with over 25 million units sold.

    Peace of mind that comes with full equipment compatibility and reliability of a leader

    Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry’s most rigorous standards.

    Smarter productivity with ability to tailor to your specific application needs

    Intuitive LCD interface provides clear information with the ability to configure the UPS locally with easy to use navigation keys. Over 15 different programmable settings including switched outlet group control allow for application specific settings, thresholds and notifications.

    Avoids costly power problems by keeping your IT equipment and data safe and available

    Network grade power conditioning protects from damaging surges and disruptive noise. Solid state automatic voltage regulation boosts low input voltage up to 30% and trims high voltage up to 12% without battery operation. Reliable battery back-up capacity to power through outages or gracefully shutdown systems











Product Specifications:

    • Output power capacity
      1.98 KWatts / 2.2 kVA
    • Max Configurable Power (Watts)
      1.98 KWatts / 2.2 kVA
    • Nominal Output Voltage
      230V
    • Output Voltage Note
      Configurable for 220 : 230 or 240 nominal output voltage
    • Output Voltage Distortion
      Less than 5% at full load
    • Output Frequency (sync to mains)
      47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal
    • Topology
      Line Interactive
    • Waveform type
      Sine wave
    • Output Connections
      (1) IEC 320 C19 (Battery Backup)
      (8) IEC 320 C13 (Battery Backup)
      (2) IEC Jumpers (Battery Backup)
    • Transfer Time
      2ms typical

    Input

    • Nominal Input Voltage
      230V
    • Input frequency
      50/60 Hz +/- 3 Hz (auto sensing)
    • Input Connections
      IEC-320 C20, Schuko CEE 7 / EU1-16P, British BS1363A
    • Input voltage range for main operations
      160 - 286V
    • Input voltage adjustable range for mains operation
      151 - 302V
    • Number of Power Cords
      1
    • Other Input Voltages
      220, 240

    Batteries & Runtime

    Communications & Management

    • Interface Port(s)
      SmartSlot
    • Control panel
      Multi-function LCD status and control console
    • Audible Alarm
      Alarm when on battery : distinctive low battery alarm : configurable delays
    • Emergency Power Off (EPO)
      Yes
    • Available SmartSlot™ Interface Quantity
      1

    Surge Protection and Filtering

    • Surge energy rating
      365Joules
    • Filtering
      Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

    Physical

    • Maximum Height
      435mm , 43.5cm
    • Maximum Width
      197mm , 19.7cm
    • Maximum Depth
      544mm , 54.4cm
    • Net Weight
      48.8kg
    • Shipping weight
      61.9kg
    • Shipping Height
      699mm , 69.9cm
    • Shipping Width
      381mm , 38.1cm
    • Shipping Depth
      762mm , 76.2cm
    • Color
      Black
    • Units per Pallet
      9.0

    Environmental

    • Operating Environment
      0 - 40 °C
    • Operating Relative Humidity
      0 - 95 %
    • Operating Elevation
      0-3000meters
    • Storage Temperature
      -15 - 45 °C
    • Storage Relative Humidity
      0 - 95 %
    • Storage Elevation
      0-15000meters
    • Audible noise at 1 meter from surface of unit
      45.0dBA
    • Online thermal dissipation
      275.0BTU/hr

    Conformance

    • Approvals
      CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE
    • Standard warranty
      3 years repair or replace (excluding battery) and 2 year for battery, optional on-site warranties available, optional extended warranties available

    Sustainable Offer Status

    • RoHS
      Compliant
    • REACH
      REACH: Contains No SVHCs
