Viewsonic 55" (54.6" viewable) Full HD Direct-lit LED Commercial Display

$1,591.53 $1,710.00

SKU: CDE5502
MODEL: 55" (54.6" viewable) Full HD Direct-lit LED Commercial Display
Product Description The ViewSonic® CDE5502 is a 55’’ (54.6” viewable) Full HD commercial display, offering the combination of cost-efficiency and ease of installation for corporate, retail and hospitality environments. Integrated with an embedded media player, the CDE5502 is able to easily playback high definition messaging via USB port. Versatile connectivity...
Quantity
Add to Wishlist

Product Description

The ViewSonic® CDE5502 is a 55’’ (54.6” viewable) Full HD commercial display, offering the combination of cost-efficiency and ease of installation for corporate, retail and hospitality environments. Integrated with an embedded media player, the CDE5502 is able to easily playback high definition messaging via USB port. Versatile connectivity options also include 2 HDMI ports, VGA, RS232 and SPDIF. With Full HD resolution, 350-nit brightness, and wide viewing angles, the slim-bezel CDE5502 delivers sharp and vivid images to ensure crisp pictures and smooth content playback. HDMI CEC pass-through support provides one-touch-play, with additional features for multiple connected devices such as HD set-top-boxes, media players, and Blu-ray™ players. An RS232 port with IR pass-through provides automated control for hospitality installation. Creating a more comfortable viewing experience, the display is equipped with Flicker-Free and Blue Light Filter technologies. In addition, free-bundled vController software offers easy maintenance and intuitive interfaces for remote management via a PC server or laptop.

Product Details

Free Bundled vController™ Software


Included vController™ software provides a simple and intuitive interface for remote management, OSD-related settings, and scheduling on deployed displays through RS232 or LAN.

Integrated USB Multimedia Player


This display features an integrated media player with a convenient USB playback function. Now photos, music, and 1080p video can be quickly displayed on-screen directly from a USB drive – without the need for a PC.

Hospitality Mode


This display is great for multi-screen setups in hotels, restaurants, sports bars, or retail outlets that require duplicated setup and customizable presets. With a USB-programmable hospitality setting, each display will have the same customized channel default, audio level, front-panel lockout, and auto power-up settings.

Control Multiple Devices


RS232 IR pass-through offers local control for set-top boxes, and other RS232 connected devices, directly with the display’s remote controller. HDMI CEC functionality offers local control of DVD players, sound systems, and other HDMI connected devices, directly with the display’s remote controller.

Enhanced Viewing Comfort
Flicker-Free technology and a Blue Light Filter help to eliminate eye strain from extended viewing periods.

Optional Display Stand
Although this display can be wall mounted for a solid and safe viewing experience, we also offer a display stand (STND-034)* for tabletop settings.

Specifications

Display

DISPLAY SIZE (IN.)
55
VIEWABLE AREA (IN.)
54.6
ORIENTATION
Landscape
LIGHT SOURCE
LED
RESOLUTION
1920 x 1080
ASPECT RATIO
16:9
STATIC CONTRAST RATIO
1,200:1
BACKLIGHT LIFE (HOURS)
30,000
BRIGHTNESS
350 cd/m2
RESPONSE TIME (TYPICAL GTG)
9ms
BEZEL WIDTH (IN.)
Top 0.50 in / Left 0.50 in / Bottom 0.57 in / Right 0.50 in
BEZEL WIDTH (MM)
Top 12.6 mm / Left 12.6 mm / Bottom 14.5 mm / Right 12.6 mm
VIEWING ANGLES
178º horizontal, 178º vertical
PANEL SURFACE
Anti-glare, Hard coating 3H
OPERATION RATING
16/7

Audio
INTERNAL SPEAKERS
10W (x2)

Connector
HDMI
2
VGA
1
3.5MM AUDIO IN
1
3.5MM AUDIO OUT
1
SPDIF AUDIO OUT
1

Power
VOLTAGE
100~240VAC (Auto Switching), 50-60Hz (universal)
CONSUMPTION (MAX)
160W
CONSUMPTION (TYPICAL)
140W

Controls
PHYSICAL CONTROLS
Power, Mute, Input, Vol +, Vol -, Up, Down, Menu
ON SCREEN DISPLAY
Picture, Sound, Advanced Options

Operating Conditions
TEMPERATURE
32-104º F (0 - 40º C)
HUMIDITY (NON-CONDENSING)
20-80%

Dimensions (metric) (wxhxd)
PACKAGING (MM)
1365 x 864 x 185
PHYSICAL WITHOUT STAND (MM)
1238.6 x 711.1 x 60

Dimensions (imperial) (wxhxd)
PACKAGING (IN.)
53.7 x 29.6 x 7.3
PHYSICAL WITHOUT STAND (IN.)
48.8 x 28.0 x 2.4

Mount
VESA COMPATIBLE
200 x 400 / 400 x 400 mm

General
REGULATIONS
CE, CB, ErP, WEEE, C-tick, cTUVus, FCC, ENERGY STAR, Mexico Energy

3 Years Limited Warranty
