Trendnet 240 W Single Output Industrial DIN-Rail Power Supply

$189.63 $270.99

SKU: TI-S24048
MODEL: 240 W Single Output Industrial DIN-Rail Power Supply
Product Description TRENDnet’s high efficiency 240 W Single Output Industrial DIN-Rail Power Supply, model TI-S24048 (Mean Well SDR-240-48), supplies up to 240 Watts (48 V, 5 A) of power to industrial PoE equipment such as switches, network cameras, and WiFi access points. This power supply comes with active PFC, an...
Quantity
Add to Wishlist

Product Description

TRENDnet’s high efficiency 240 W Single Output Industrial DIN-Rail Power Supply, model TI-S24048 (Mean Well SDR-240-48), supplies up to 240 Watts (48 V, 5 A) of power to industrial PoE equipment such as switches, network cameras, and WiFi access points. This power supply comes with active PFC, an integrated DIN-rail mount, and overload current protection.

Product Details

240 Watt Power


Provides up to 240 Watts (48 V, 5 A) of power for PoE devices such as switches, network cameras, and access points

Active PFC


The built-in active Power Factor Controller (PFC, PF > 0.93) helps eliminate unusable reactive power

Overload Protection


Overload/short circuit/over voltage/over temperature protection

Full Load Test


This power supply undergoes a 100 % full load burn-in test

Passive Cooling


Cooling by free air convection

DIN -Rail Mount


Metal enclosure with integrated DIN-rail mount

Extreme Temperatures


Rated for an operating temperature range of -25 to 70 °C (-13 to 158 °F)

Safety Certifications


Certified for UL 508 and TUV EN60950-1

Electro Magnetic Emission/Immunity


Compliance to EN55011, EN55022 (CISPR22), EN61204-3 Class B, EN61000-3-2/3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN55024, EN61000-6-2, EN61204-3, heavy industry level, criteria A, SEMI F47, and GL approved

Vibration Resistant


Rated for vibration (IEC 60068-2-6)

LED Indicator


LED indicator confirms power to the unit

Specifications

Interface

Input: 100-240 V AC, 50/60 Hz, 1.8 A 125-370 V DC
Output: 240 Watts, 48 V, 5 A
DIN-rail: TS-35/7.5 or 15

Housing
Metal case
DIN-rail mount
LED indicator confirms power to the unit

Special Features
DC OK relay contact
150% peak load capacity
Short circuit/overload/over voltage/over temperature protection
Protection type: shut down and repower

Operating Temperature
- 25 to 70 °C (- 13 to 158 °F)
Max. 95 % non-condensing

MTBF
1,693,000 hours

Dimensions
40 x 125 x 114 mm (1.6 x 4.9 x 4.5 in.)
Weight
1.03 kg (2.3 lbs.)

Certifications (Mean Well)
CE
UL 508CB 60950-1

1 Year Warranty
