Trendnet Outdoor 1.3 MP HD PoE Day/Night Network Camera

$122.18 $174.27

SKU: TV-IP320PI
MODEL: Outdoor 1.3 MP HD PoE Day/Night Network Camera
Product Description The Indoor / Outdoor 1.3 MP HD PoE IR Network Camera, model TV-IP320PI, provides powerful 1.3 megapixel HD night vision in complete darkness for up to 30 meters (100 ft.). This ultra-compact camera is outdoor ready with an IP66 weather rated housing. It comes with a free Apple®...
Quantity
Add to Wishlist

Product Description

The Indoor / Outdoor 1.3 MP HD PoE IR Network Camera, model TV-IP320PI, provides powerful 1.3 megapixel HD night vision in complete darkness for up to 30 meters (100 ft.). This ultra-compact camera is outdoor ready with an IP66 weather rated housing. It comes with a free Apple® and Android™ mobile app and Complimentary pro-grade software to manage up to 32 TRENDnet cameras.

Product Details

PoE
Save installation costs with Power over Ethernet (IEEE 802.3af)

Outdoor Ready
Outdoor IP66 weather rated and an operating temperature range of -30 – 60 °C (-22 – 140 °F)

1.3 Megapixel
Record 1280 x 960 pixel video at 30 fps in H.264 compression

Night Vision
Night vision up to 30 meters (100 ft.) in complete darkness

Smart IR
Dynamic IR adjustment optimizes night visibility

D-WDR
Digital Wide Dynamic Range improves video quality in high contrast lighting environments

Multi-Language Interface
Support for English, French, Spanish, German, and Russian

Dynamic DNS Support
Support for dyn.com and NO-IP.org

Storage
SMB/CIFS support with notification if storage drive is full

Motion Detection
Create motion detection windows with separate sensitivity settings and event triggers

Recording Schedule
Define a weekly recording schedule

Tamper Detection
Receive tamper detection video clips via email

IPv6
IPv6 support

ONVIF
ONVIF v2.2 compliant

Free Apps
See live video on a mobile device with free iOS® and Android™ apps

Complimentary Software
Complimentary pro-grade software to manage up to TRENDnet 32 cameras

Specifications

Lens
Focal length: 4 mm
Focal depth: 20 cm +
Aperture: F2.0
Board lens
Sensor: 1/3” progressive scan CMOS

Viewing Angle
Horizontal: 70°
Vertical: 52°
Diagonal: 89°

Zoom
User-defined digital zoom

Minimum Illumination
IR off: 0.01 lux
IR on: 0 lux
30 meter IR illumination distance
Smart IR

Video
D-WDR: 0-100 scale
Shutter speed: 1/3 - 1/10,000
H.264: 1280 x 960 up to 30 fps
MJPEG: 704 x 480 up to 30 fps

Hardware Standards
IEEE 802.1X
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3af

Device Interface
10/100 Mbps PoE port
Power port (for non-PoE installations, power adapter sold separately (12VDC1A))
Grounding point
Integrated articulated mounting base
Reset button

Housing
Weather rating: IP66

Network Protocol
IPv4, IPv6, UDP, TCP, ICMP, ONVIF v2.2 DHCP, NTP, DNS, DDNS, SMTP, FTP, SNMP (v1, v2c, v3)
NFS, SMB/CIFS
HTTP, HTTPS
PPPoE
UPnP, Bonjour, RTSP, RTP, RTCP, SSL

Operating Temperature
-30 - 60 °C (-22 - 140 °F)

Operating Humidity
Max. 95% non-condensing

Certifications
CE
FCC
UL 60950

Dimensions
60 x 60 x 152 mm (2.4 x 2.4 x 6.2 in.)

Power
Input: PoE (802.3af)
Consumption: 7 Watts max.

Optional Power Supply (Sold separately)
Output: 12 V DC 1 A
5.5 mm barrel connector
TRENDnet power adapter, model 12VDC1A, sold separately

Management Interface
Multi-language support: English, French, German, Russian, and Spanish
IP address filter
QoS traffic prioritization
Time, date, and text overlay
Image settings: brightness, contrast, saturation, sharpness, smart IR, exposure time (1/3 – 1/100,000), video standard, day/night switch, sensitivity, switch time, mirror, D-WDR, white balance, digital noise reduction
D-WDR enhances video quality in high contrast daytime lighting
3D Digital Noise Reduction enhances night vision quality
Scheduled recording: continuous and motion detection
Video storage: to computer, NAS, SMB/CIFS share, or through software
Motion detection fields: define custom motion detection areas, motion sensitivity, and dynamic motion analysis
Privacy masks: define custom privacy mask areas
Tamper detection: email notification if the viewing field darkens suddenly
Browser video playback: advanced playback functionality with visual timeline displaying detected motion and scheduled recordings
Alert messages: storage full, storage error, and illegal login
Snapshot: real time snapshot, motion detection with schedule, video tamper detection with schedule
Supported dynamic DNS services: Dyn.com and NO-IP.com
Management Setting: maximum 32 user accounts
Supports remote management
Compatibility: Internet Explorer® 9.0 or higher, Safari® 4.0 or higher

TRENDnetView Pro Software
Supports up to 32 TRENDnet cameras
Multiple language support
Set recording options (motion detection, schedule, event trigger)
Search and playback
Custom viewing modes and options
Compatibility: Windows® 10, 8.1, 8, 7, Vista, XP, Windows Server® 2003, 2008

TRENDnetVIEW App
Free iOS® and Android™ app
View your camera on your mobile device
Take snapshots
Zoom

3 Year Warranty
