Trendnet Mini-GBIC Dual Wavelength Single-Mode LC Module

$90.79 $128.63

SKU: TEG-MGBS20D3
MODEL: Mini-GBIC Dual Wavelength Single-Mode LC Module
Product Description TRENDnet’s TEG-MGBS20D3 when paired with the TEG-MGBS20D5 creates a long distance, single strand fiber solution with a range of up to 20 KM (12.4 miles). Alternatively grow your pre-existing two-strand fiber connection, and turn it into two separate single-strand fiber connections. The SFP interface is compatible with standard...
Quantity
Add to Wishlist

Product Description

TRENDnet’s TEG-MGBS20D3 when paired with the TEG-MGBS20D5 creates a long distance, single strand fiber solution with a range of up to 20 KM (12.4 miles). Alternatively grow your pre-existing two-strand fiber connection, and turn it into two separate single-strand fiber connections. The SFP interface is compatible with standard SFP slots and offers a 1000BASE-LX SFP interface.


Fiber Applications

Long distance fiber networking for industrial, manufacturing, corporate and educational campus applications.



Fiber Mode / Distance
Single Mode transceiver spans distances up to 20 km (12.4 miles) and supports up to 1.25 Gbps throughput speeds.


Compatibility
Compatabile with TRENDnet SFP switches, adapters and many third-party SFP solutions

Product Details

Hot-Pluggable SFP


Hot-pluggable SFP transceiver compatible with a MSA compliant SFP slot

Bi-Directional Fiber


Transmit: 1310 nm / Receive: 1550 nm, pair with TEG-MGBS20D5 or compatible SFP module

Fiber Distance


Supports networking for distances up to 20 km (12.4 miles)

Fiber Port


LC-type simplex connector

Operating Temperature


Rated for an operating temperature range of 0 to 70 °C (32 to 158 °F)


Specifications

Standards
IEEE 802.3z
ANSI Fiber Channel compliant
Class 1 Laser

Device Interface
SFP MSA Compliant
Simplex LC connector

Data Transfer Rate
1.25 Gbps

Wavelength
TX: 1310 nm
RX: 1550 nm

Optical Output Power
-3 ~ -9 dBm

Distance
20 km (12.4 miles)

Special Features
Hot pluggable
Bi-directional (WDM) SFP module

Sensitivity
-23 dBm

Power Consumption
0.8 watts

Operating Temperature
0 – 70 °C (32 - 158 °F)

Operating Humidity
Max. 85% non-condensing

Dimensions
57 x 13 x 12 mm (2.2 x 0.5 x 0.5 in)

Certifications
CE
FCC

3 Year Warranty
